Medium Pressure Water Flow Control Valve
1000 INR/Unit
Product Details:
- Connection Other
- Color SILVER & BLACK
- Application WATER
- Usage WATER APPLICATION
- Size 1/2"
- Material Plastic
- Temperature Normal Temperature
- Click to view more
X
Medium Pressure Water Flow Control Valve Price And Quantity
- 5000 Unit
- 1000 INR/Unit
Medium Pressure Water Flow Control Valve Product Specifications
- SILVER & BLACK
- Water
- WATER
- Other
- Other
- Control
- 1/2"
- Normal Temperature
- WATER APPLICATION
- Plastic
- Other
- 1/2"
Medium Pressure Water Flow Control Valve Trade Information
- Cash in Advance (CID)
- 5000 Unit Per Month
- 1 Days
- Contact us for information regarding our sample policy
- CORROGATED BOXES
- All India
Product Description
Features:- Complete body is of polypropylene PP with SS 316 ball.
- Connection threading will be as per IS 554 BSPT, ISO 7-1.
- Minimum length of FCV will be 79mm +/- 2mm.
- Flow control valve will be assembly of 2 parts i.e. body with outlet & NRV and SS 316 Ball.
- Flow control valve works on self operating float concept.
- Flow control valve fits properly in saddle and there will be no gaps and voids between pipe and saddle.
- Flow control valve has unidirectional flow (one way flow)
- It has non return valve at the bottom.
- Marking on body
- Direction of flow Arrow will be marked on body.
- So it does not cause any confusion while installation.
- Size Size will be mentioned on body Exetc
- Manufacturers name.
- Manufacturers logo.
- Flow5LPM, 10LPM or 15LPM etc.
- Advantages
- One single body, No press fitted body part. No chance of leakages.
- WRAS & NSF approved polypropylene.
- Equivalent strength of Stainless steel.
- Rust free.
- Total avoidance of CNC and VMC machining process.
- Fastest manufacturing.
- Cost effective.
Technical Specification
| Country of Origin | Made in India |
| Material | POLYPROPYLENE |
| Colour | Silver & Blue |
| Thread Size | 15mm |
| I Deal In | New Only |
| Finishing | Matt finish |
| Model Name/Number | 7774001062 |
| Material Grade | MI3530 |
| Design | Patented |
| End Connection Type | threaded |
| Flow Range | 0.5 bar to 1 bar |
| Type | Flow Control Valve |
| Temperature | atmospheric |
| Port Size | 1/2 Inch |
| Mounting Position | Vertical |
| Construction | Plastic |
| Brand | Kaizen |
| Pressure | Medium Pressure |
| Usage/Application | Water |
| Valve Size | 1/2'' |
| Media | Water |
